Electric Plastic Sole Injection Molding Machine 4 Station Single Color

Electric Plastic Sole Injection Molding Machine 4 Station Single Color

  • High Light

    Electric Plastic Sole Injection Molding Machine

    ,

    4Station Plastic Sole Injection Molding Machine

  • Supply Ability
    1000 Set/ Per Month
  • Model NO.
    KK-HC-T0401-A
  • Max. Mould Dimensions
    420*420 Mm
  • Transport Package
    Standard Export Packaging
  • Specification
    4300*3600*2500mm
  • Trademark
    KINGKUNG
  • Origin
    Fujian, China
  • HS Code
    8477800000
  • Condition
    New
  • Power Supply
    Electric
  • Applicable Material
    Plastic
  • Function
    Making Sole
  • Station
    4
  • Clamping
    220 Ton
  • Customization
    Available | Customized Request

Electric Plastic Sole Injection Molding Machine 4 Station Single Color



PVC and TR single color shoe sole injection molding machine

We are the supplier of various kinds of shoe making machinery, please do not hesitate to contact us, if you have any inquiry

Machine pic:
PVC and Tr Single Color Shoe Sole Injection Molding Machine

Technical data:
Item Unit KK-HC-T0401-A
Number Of Station Station 4
Clamping Ton 220
Max.Mould Dimensions mm 420*420
Max.Opening Stroke Of the Mold mm 450
Argles Of Rotating Head   0°-90°
Screw Diameter mm 50-65
Scrwe Speed rpm 0-260
Thermal Zone Of barrel No. 4+1
Injection Pressure Mpa 180
Injection Volume cm3 1200
L/D L/D 22
Extrusion Unit KW 22
Max.Electric Consumption KW 46
Average Power Consurnption KW 30
Measurement(L*W*H) mm 4300*3600*2500
Weight Approximate Ton 15

This machine can only produce monochromatic products
Applicable Material: TR,TPU,TPR,PVC
