20 Meter Double Layer Conveyor Sports Shoe Production Line

This 20-meter double layer conveyor production line is professionally developed for sports shoe mass manufacturing. Adopting innovative upper and lower double-layer structure, it separates vamp and outsole processing independently and realizes synchronous dual-station operation.

Different from traditional single-layer production lines, it doubles the production efficiency without expanding workshop area, perfectly solving the pain points of low output and large space occupation in shoe factories. The overall 20-meter integrated layout covers complete procedures of gluing, heating, activation and conveying, forming a standardized sports shoe assembly process.

Equipped with independent SCR intelligent temperature control modules for upper and lower layers, the conveyor line supports 0-120℃ free temperature adjustment and precise constant temperature control. The built-in infrared uniform heating device ensures even glue heating and full activation, effectively improving the bonding strength of shoe sole and vamp.

The conveyor speed can be adjusted steplessly according to different shoe materials and production beats, adapting to various sports shoe, sneaker and casual shoe production standards, with strong compatibility and flexible parameter adjustment.

The production line adopts upgraded energy-saving heating components, which reduces power consumption by nearly 30% compared with traditional equipment, greatly lowering the long-term production cost of the factory. The whole machine uses thickened industrial steel frame and reinforced conveyor structure, with stable operation, no deviation and no shaking during long-time continuous work.

It supports 8-hour stable batch production with a daily output of 1500 pairs of sports shoes. The optimized transmission system reduces mechanical failure rate, ensures continuous and stable production progress, and improves factory delivery efficiency.
