Shoe Anti-Slip Pad Injection Machine
,Outsole Stud Injection Machine
,Shoe Grip Pad Molding Machine
-
Number Of Stations6 (rotary)
-
Injection Volume100cc
-
Screw Diameter35mm
-
Shot Accuracy±0.5g
-
Clamping Force30 Tons
-
Min Part Size5mm Diameter
-
Production Rate800-1500 Pieces/hour
-
Motor Power7.5KW
-
Voltage380V/50Hz 3-Phase
-
Weight2800kg
-
Warranty1 Year
-
UsageAnti-Slip Pad Injection
-
Place of OriginChina
-
Brand NameKingkung
-
Model NumberKK-PAD-6S
Shoe Anti-Slip Pad And Outsole Stud Injection Molding Machine
Shoe Anti-Slip Pad And Outsole Stud Injection Molding Machine
Product Overview
The Shoe Anti-Slip Pad and Outsole Stud Injection Molding Machine is a specialized injection system for manufacturing anti-slip pads, traction studs, and grip enhancement components for footwear outsoles. These components are critical for sports shoes, safety shoes, hiking boots, and any footwear requiring enhanced ground traction.
This vertical injection machine features a rotary table with 6 mold stations, allowing continuous production with simultaneous injection, cooling, and part removal. The injection unit handles TPR, TPU, and rubber compounds with precision shot control (±0.5g) for consistent part quality. Anti-slip pads as small as 5mm diameter can be produced with high repeatability.
The quick-change mold system supports multiple product configurations on the same machine. With production rates of 800-1500 pieces per hour depending on part size and material, this machine provides the capacity needed for large-scale shoe manufacturing operations.
Key Features
- 6-station rotary table for continuous production
- Vertical injection design for insert molding capability
- Precision shot control ±0.5g for consistent quality
- Multi-zone PID temperature control
- Quick mold change system for product variety
- Automatic part ejection and collection
- 1 Year warranty
Technical Specifications
| Parameter | Value |
|---|---|
| Number of Stations | 6 (rotary) |
| Injection Volume | 100cc |
| Screw Diameter | 35mm |
| Shot Accuracy | ±0.5g |
| Clamping Force | 30 Tons |
| Min Part Size | 5mm diameter |
| Production Rate | 800-1500 pieces/hour |
| Motor Power | 7.5KW |
| Voltage | 380V/50Hz 3-Phase |
| Machine Weight | 2800kg |
Applications
Manufactures anti-slip pads for sports shoes, cleats for soccer/football shoes, traction studs for hiking boots, grip pads for safety shoes, and decorative sole elements. Compatible with TPR, TPU, PVC, and rubber materials in various hardness grades.
Frequently Asked Questions
Q: What is the smallest part this machine can produce?
A: Parts as small as 5mm diameter can be produced with consistent quality. Mold design affects minimum size capabilities.
Q: Can different color materials be used in the same run?
A: Each production run uses one material/color. For multi-color products, parts from different runs can be assembled, or a multi-injection machine configuration is available.
Q: How are the finished parts attached to shoe soles?
A: Parts can be produced as insert-molded components (placed in sole molds) or as standalone pads that are glued onto finished soles.
Q: What is the typical mold cost?
A: Mold costs vary based on cavity count and complexity. Single-cavity molds start around $500, while multi-cavity molds range from $2,000-$8,000. We can recommend mold suppliers.
Q: Are different compound formulations supported?
A: Yes, the temperature and pressure settings are fully adjustable for different TPR, TPU, PVC, and rubber formulations. Up to 50 material recipes can be stored in the PLC.
