Automatic PVC Injection Molding Shoe Machine 160R/Min Electric

Automatic PVC Injection Molding Shoe Machine 160R/Min Electric

  • High Light

    Automatic PVC Injection Molding Shoe Machine

    ,

    160R/Min PVC Injection Molding Shoe Machine

    ,

    Electric PVC Shoe Injection Moulding Machine

  • Certification
    CE
  • Supply Ability
    100set/Month
  • Trademark
    HX
  • Origin
    China
  • HS Code
    8443198000
  • Condition
    New
  • Power Supply
    Electric
  • Function
    Shoemaking Line
  • Transport Package
    Plywood
  • Specification
    100*150mm
  • Customization
    Available | Customized Request

Automatic PVC Injection Molding Shoe Machine 160R/Min Electric

Double Color Automatic PVC Directly Injection Moulding Machine

Product Description



Item

Unit

Specification

Color



Double

Number of station

Pcs

20

Screw diameter

mm

75

Screw rotating speed

r/min

0-160

Screw length and diameter ratio



18:1

Max injection capacity

Cm3

580

Plastifying capacity

g/s

40

Sliding platform travel

Mpa

5.0

Travel for lifting the cramp

Mpa

3.0

Clamping way



scissors

Mention last trip

mm

60

Shoe cramp height

mm

21-260

Mould frame dimensions(LxWxH)

mm

340x180x60

Total power of the whole machine

kw

35.5

Outline dimensions of the whole machine (LxWxH)

mm

6290x6150x1955

Total weight of the whole machine

kg

14500


Double Color Automatic PVC Directly Injection Moulding Machine
